LUFT 3 Pulmonary Ventilator

R5.00

N/A

Description

  • Advanced and complete pulmonary ventilator for intensive care.
  • 17 ”touch-sensitive monitor for easy viewing and intuitive control.
  • 13 ventilation modes, from traditional to double control.
  • Advanced ventilatory mechanics for patient diagnosis.
  • It allows self-flow oxygen therapy with fine adjustments.
  • Sufficient internal battery for all cases, up to 6 hours of autonomy.



The lung ventilator for Intense Care Units (ICU) LUFT3, counts with integrated 17″ touch screen technology and offers a complete range of ventilation modes which allows the monitoring of the patient’s condition.



VENTILATION MODES

ADULT/PEDIATRIC NEONATAL
  • VCV assisted/controlled
  • PCV assisted/controlled
  • PSV/CPAP
  • PRVC assisted/controlled
  • SIMV (VCV) + PSV
  • SIMV (PCV) + PSV
  • MMV + PSV
  • PSV + assured VT
  • Biphasic pressure (APRV + PSV)
  • NIV
  • HFNC


  • VCVassisted/controlled
  • PCV assisted/controlled
  • PSV/CPAP
  • SIMV (PCV) + PSV
  • Continuous flow assisted/controlled
  • Nasal CPAP
  • HFNC



FUNCTIONALITY AND PERFORMANCE

STRESS INDEX PRVC
The stress index is performed with
minimal interference in the ventilatory
cycle and results in a numerical value of
easy interpretation, promoting a
practical, safe and effective analysis of
the patient ventilation. It is a measure of
respiratory the stress caused in the
alveoli either by collapse or hyperdistension.
It combines the best of convetional
controlled ventilation modes of volume
and pressure, providing the volume
adjusted by the operator with as little
pressure as possible.
The function uses free flow waveform
formation, control with feedback of the
compliance and resistance of the patient



SPECIAL FEATURES

  • 100 % oxygen up to 20 min. with automatic alarm silence;
  • Adaptation of the patient’s interface or change of the circuit with
  • recalibration without having to turn off the equipment and keeping track
    of the patient’s log;
  • Automatic theoretical weight calculation and interface selection
    according to the patient;
  • Altitude compesation;
  • Configuration of the monitored variables;
  • Flow curve 50 % descending;
  • Intuitive Interface;
  • Gas measurement with BTPS correction;
  • Smart ventilator, records the user preference after 10 uses.
  • LCD Screen tilt angle adjustment
  • Log for 1000 alarms and events with date and time

Additional information

LUFT 3 Pulmonary Ventilator

LUFT 3 Pulmonary Ventilator

Quick Comparison

SettingsLUFT 3 Pulmonary Ventilator removeAJ-2510 Medical Use Oxygen Concentrator removeINFU-Z 1000 Infusion Pump removeAJ-3000D 15 inch High Performance Multi Parameter Patient Monitor removeHospital ICU/CCU Electrical Bed BA9900-WAS removeHospital ICU/CCU Electrical Bed BA9000 remove
NameLUFT 3 Pulmonary Ventilator removeAJ-2510 Medical Use Oxygen Concentrator removeINFU-Z 1000 Infusion Pump removeAJ-3000D 15 inch High Performance Multi Parameter Patient Monitor removeHospital ICU/CCU Electrical Bed BA9900-WAS removeHospital ICU/CCU Electrical Bed BA9000 remove
ImageAJ-2510 Medical Use Oxygen ConcentratorAJ-3000D 15 inch High Performance Multi Parameter Patient Monitor
SKU
Rating
PriceR5.00R5.00R5.00R5.00R5.00R5.00
Stock
Availability
Add to cart

Description
Content
  • Advanced and complete pulmonary ventilator for intensive care.
  • 17 ”touch-sensitive monitor for easy viewing and intuitive control.
  • 13 ventilation modes, from traditional to double control.
  • Advanced ventilatory mechanics for patient diagnosis.
  • It allows self-flow oxygen therapy with fine adjustments.
  • Sufficient internal battery for all cases, up to 6 hours of autonomy.
  The lung ventilator for Intense Care Units (ICU) LUFT3, counts with integrated 17" touch screen technology and offers a complete range of ventilation modes which allows the monitoring of the patient’s condition.

VENTILATION MODES

ADULT/PEDIATRIC NEONATAL
  • VCV assisted/controlled
  • PCV assisted/controlled
  • PSV/CPAP
  • PRVC assisted/controlled
  • SIMV (VCV) + PSV
  • SIMV (PCV) + PSV
  • MMV + PSV
  • PSV + assured VT
  • Biphasic pressure (APRV + PSV)
  • NIV
  • HFNC

  • VCVassisted/controlled
  • PCV assisted/controlled
  • PSV/CPAP
  • SIMV (PCV) + PSV
  • Continuous flow assisted/controlled
  • Nasal CPAP
  • HFNC
  FUNCTIONALITY AND PERFORMANCE
STRESS INDEX PRVC
The stress index is performed with minimal interference in the ventilatory cycle and results in a numerical value of easy interpretation, promoting a practical, safe and effective analysis of the patient ventilation. It is a measure of respiratory the stress caused in the alveoli either by collapse or hyperdistension. It combines the best of convetional controlled ventilation modes of volume and pressure, providing the volume adjusted by the operator with as little pressure as possible. The function uses free flow waveform formation, control with feedback of the compliance and resistance of the patient


SPECIAL FEATURES

  • 100 % oxygen up to 20 min. with automatic alarm silence;
  • Adaptation of the patient’s interface or change of the circuit with
  • recalibration without having to turn off the equipment and keeping track of the patient’s log;
  • Automatic theoretical weight calculation and interface selection according to the patient;
  • Altitude compesation;
  • Configuration of the monitored variables;
  • Flow curve 50 % descending;
  • Intuitive Interface;
  • Gas measurement with BTPS correction;
  • Smart ventilator, records the user preference after 10 uses.
  • LCD Screen tilt angle adjustment
  • Log for 1000 alarms and events with date and time

Features:

*Oxygen density display

*Power off alarm

*Abnormal alarm

*Voltage alarm

*Time counting

*Overload protection

*Compressor protection

*Ultra quiet design

*Adopts american PSA technology, use physical method to separate pure oxygen from air;

*Advanced oil-free compressor, save 10% power energy;

*24 hours continous working available,10000 hours working time warranty;

*8 years experience and technology, make sure the stable and reliable quality;

Technical reference:

Appearance: streamlined design, more fashionable

Display screen: big LCD screen, easy to operate

Internal structure: compact, reasonable

Power consumption: compared to peers by 20%-45%, more economical

Flow meter(L/MIN): 5L/MIN

Oxygen density: 93%±3%

Noise dB(A):≦53

Dimension(L*W*H)MM: 395*310*610

Power: ≦480

N.W.: 23kg

Continuous working time: 10000 hours

Useful:

To strengthen your heart, reducing the risk of heart attacks;

To detoxify your blood, raise enery level

To improve strength&build endurance

To revitalize the skin

To prevent disease, relieve hangovers

To help fight off depression

Optional function:

Nebulizer function

Remote function

Oxygen density alarm function

Features

Clear, Easier and Faster - Touchable Keypad * Easy and Fast way to setup - Various Displays * FND displays numerical data clearly. - User Friendly and Ergonomic Design * Simple setup process makes user feels comfortable and variety display makes user gets complete information at one glance. * Proper weight & superb grip for easy carriage.   Alarm(Visual & Audio) Function. - Door Open - Air Bubble Sensing - Low Battery - Infusion Completion - Occlusion * 1:100~400 mmHg, 5: 300~700 mmHg, 9: 600 ~ 1 000 mmHg - Drop Error Sensing by Drop Sensor * Including Empty error * External Option. - Device Malfuntion * Status of equipment and Alarm. - Start Reminder Alarm * After Pause Setting Time.   Safety Function. - Keypad Lock - All key don't work except START and ON/OFF key. - Door Open. - Air Sensor. - Occlusion Sensor - Drop Sensor - Nurse Call (Option) *Each unit can be connected with nurse call system   Various Functions - Self Testing - Every time unit turns on, self testing is proceeded. - K.V.O (Keep Open Vein) - When the infused volume has been reached, flow rate turns into K.V.O rate automatically. - Retain Memory - Last setting value will be retained. - Remaining Time Display. - Alarm Repeat - Purge - Faster infusion than normal state. - Buzzer Level - 9 steps. - Titration(Changing the Flow Rate during infusion) - Micro / Macro Control - Infusion Setup -  Flow rate / Infused volume / Infusion time. - Interface ( Communcation) - USB - Less Noise (Micro Stepping Motor) - Easy Replacement of Battery. - CE, ISO13485, KFDA certified.

specification

Product Name
     Volumetric Infusion Pump
Model Name
     INFU-Z 1000
Pump System
     Peristaltic Finger System
Control Mode
     Volumetric Control
Flow Range
     0.1 ~ 999.9ml/h
Volume Range
     1 ~ 9999ml
K.V.O.
     OFF, 0.1 m/h, 1~5 ml/h
Bolus Rate
     1 ~ 999ml/h
Occlusion Limit
     1: 100~400mmHg, 5: 300~700mmHg, 9:
     600~1000mmHg
Accuracy
     ±5%
Display
     FND 7 Segments
Battery
     Li-ion Rechargeable Battery
     - 2200mA/h, 10.8V
     - Operating Time: approx. 10 hours (Flow Rate 25ml/h)
     - Recharging Time: approx. 8 hours
Electric Shock Protection
     Class I, Type CF
Waterproof
     IPX2 Standard
Power Input
     AC 100 ~ 240 VAC, 50 ~ 60Hz (Fuse : 250V, T1.6A),
Power Consumption
     40VA
External Source
     DC 12~18V
Weight
     1.7 Kg
Size(W×H×D)
     135mm×118mm×212 mm
Interface
     USB Cable (Baud rate: 19200 bps, Data 8 bit)
Macro/Micro
     Total   Volume
     Macro : 1~9999 ml
     Flow Rate
     Micro : 0.1~999.9 ml/h
     Macro : 1~999 ml/h
History Log
    2000 events
Using Environment
     Operation Temperature: 5°C to 40°C
     Storage Temperature: -10°C to 60°C
     Humidity: 20% to 95% RH
     Operation Altitude: 700mbar ~ 1060mbar
Accessory
     Operation Manual (English), AC Power Cable, IV Pole Clamp,
     Drop Sensor (External Option, drop rate range depends on IV sets)

Accessory

AJ-3000D multi-parameter patient monitor is a robust patient monitor, small enough to move around, yet flexible enough to adapt to your particular needs. With a variety of optional extras, including arrhythmia and ST analysis, EtCO2 measurement and double IBP, AJ-3000D multi-parameter patient monitor is configurable to suit your requirements. Purchase only the advanced features that you need and nothing more. With NIBP recall and extensive data storage capability, AJ-3000D multi-parameter patient monitor is particularly well-suited for use in peri-anesthesia and critical care environments. Rich in functions, conveniently adaptable and pleasingly affordable, AJ-3000D multi-parameter patient monitor may be just the monitor for your department.

Features & Advantage

  • 6 Standard parameters: ECG, RESP, NIBP, SPO2, 2-TEMP, PR/HR.
  • 15"high resolution color TFT LCD display.
  • Real time S-T segment analysis, pace-maker detection.
  • Indication of Incorrect manipulation and malfunction analysis.
  • Patient info input management function
  • Multi-lead ECG waveforms display in phase.
  • Large volume of tabular and graphic trends information storage and easy to recall.
  • Capture dynamic waveforms.
  • Efficient resistance to interference of defibrillator and HF knife.
  • UP to 2 hours working capacity of built-in rechargeable battery.
  • Unique accessory management cabinet.
  • Networking capacity.
  • Option: Touch Screen,ETCO2, IBP, and 2-IBP

Product Features

  • Digital Weighing Scale with segment LCD display and control panel on the foot board
  • Zero scale function
  • Bed exit alarm system
  • Under Bed Light
  • Steel construction finishing with scratch and chip resistant of hard epoxy powder coating
  • Split fold down PE safety side rails with one-hand operation
  • PE Head & Foot boards with locking mechanism for easy attachment, detachment and can be cleaned easily
  • Backrest side rail with embedded control buttons
  • Quick CPR release lever for flattening the backrest located at both sides of the bed
  • Nurse lock and nurse control located at foot board
  • Nurse lock to lock out total or individual function of control buttons
  • Auto contour function to avoid patients slipping down while performing cardiac chair position
  • Hi-Lo, Backrest, Kneerest, Trendelenburg and Reverse Trendelenburg by electrical motorized
  • Backrest with X-Ray radio Translucent base complete with X-Ray cassette tray
  • Perforated mattress support base
  • Four high-quality 150mm diameter German Twinwheel with central locking system
  • 6 provisions for IV pole attachment
  • 4 provisions for monkey pole
  • 2 drainage bag holders provided
  • With 4 corner rotating bumpers
  • IV drip pole storage

 Technical Specifications

  • Backrest: 0° - 70°
  • Legrest: 0° - 35°
  • Kneerest: 0° - 20°
  • Trendelenburg & Reverse Trendelenburg: -15° to +15°
  • Auto contour
  • Cardiac Chair Position
  • Vascular Position
  • Overall Approx Dim(mm): 2273(L) x 1060(W) x 488 - 788(H)
  • Safety load capacity: 250kg UDL


Product Features

  • Steel construction finishing with scratch and chip resistant of hard epoxy powder coating
  • PE Head & Foot boards with locking mechanism for easy attachment, detachment and can be cleaned easily
  • Split fold down PE safety side rails with one-hand operation
  • Backrest with X-Ray radio Translucent base complete with X-Ray cassete tray
  • Perforated mattress support base
  • Four high-quality 150mm diameter German Twinwheel with central locking system (free, steer and total brakes)
  • Hi-Lo, Backrest, Kneerest, Trendelenburg and Reverse Trendelenburg by electrical motorized
  • Control panel Embedded onto the backrest side rails internally, and externally
  • Nurse lock and nurse handheld control located at foot end
  • Nurse lock to lock out total or individual function of control buttons
  • Nurse handheld control with CPR button to neutralize bed position during emergency
  • Quick CPR release lever for flattening the backrest located at both sides of the bed
  • Auto contour function to avoid patients slipping down while performing cardiac chair position
  • 6 provisions for IV pole attachment
  • 4 provisions for monkey pole
  • 2 drainage bag holders provided
  • With 4 corner rotating bumpers
  • IV drip pole storage

Technical Specifications

  • Backrest: 0o - 70o
  • Legrest: 0o - 35o
  • Kneerest: 0o - 20o
  • Trendelenburg & Reverse Trendelenburg: -15o to +15o
  • Auto contour
  • Cardiac Chair Position
  • Vascular Position
  • Overall Approx Dim(mm): 2245 (L) x 1090(W) x 480-780mm(H)
  • Safety load capacity: 250kg UDL
WeightN/AN/AN/AN/AN/AN/A
DimensionsN/AN/AN/AN/AN/AN/A
Additional information
LUFT 3 Pulmonary Ventilator

LUFT 3 Pulmonary Ventilator

AJ-2510 Medical Use Oxygen Concentrator

AJ-2510 Medical Use Oxygen Concentrator

INFU-Z 1000 Infusion Pump

INFU-Z 1000 Infusion Pump

AJ-3000D Multi Parameter Patient Monitor

AJ-3000D Multi Parameter Patient Monitor

Hospital ICU/CCU Electrical Bed BA9900-WAS

Hospital ICU/CCU Electrical Bed BA9900-WAS

Hospital ICU/CCU Electrical Bed BA9000

Hospital ICU/CCU Electrical Bed BA9000

Select the fields to be shown. Others will be hidden. Drag and drop to rearrange the order.
  • Image
  • SKU
  • Rating
  • Price
  • Stock
  • Availability
  • Add to cart
  • Description
  • Content
  • Weight
  • Dimensions
  • Additional information
  • Attributes
  • Custom attributes
  • Custom fields
Click outside to hide the comparison bar
Compare
